Model AWB14
Wind Load Rated
Aluminum Condensing Unit
Wall-Mount Bracket

Model AWB14
Wind Load Rated Aluminum Condensing Unit Wall-Mount Bracket

Product Description

    FBC 8th Edition (2023) compliant.
    6061-T6 alloy temper aluminum construction.
    AWB14-WLR models rated for windload up to 170 psf.
    Original raised-seal engineering drawings available at an additional cost.
    Optional vibration pad is made from recycled rubber to isolate vibration from condensing unit.



Standard Sizes

Part No. Bracket Length Bracket Spacing Inner Spacing Max Unit Size
AWB143036-WLR24 30" 24" 14" 30" x 30"
AWB143636-WLR30 36" 30" 20" 38" x 36"
AWB144836-WLR36 48" 36" 26" 45" x 48"
